Introduction

Procedural content generation allows game developers to create diverse, replayable environments without manually designing each level. In this tutorial, we’ll cover a step-by-step method for generating a cave-like 2D map using cellular automata and show how to integrate the result into your engine of choice.

We’ll touch on:

Representing your map in code
Seeding and smoothing with CA
Ensuring connectivity
Rendering and integrating into a game loop
Extending with variations

1. Map Representation

We’ll store tiles in a 2D array:

enum TileType { Wall, Floor }
TileType[,] map = new TileType[width, height];

// Initialize all tiles as Wall
for (int x = 0; x < width; x++)
for (int y = 0; y < height; y++)
map[x, y] = TileType.Wall;

Helper functions for bounds and neighbors:

bool InBounds(int x, int y) =>
x >= 0 && x < width && y >= 0 && y < height;

IEnumerable<(int, int)> Neighbors4(int x, int y) {
yield return (x+1, y);
yield return (x-1, y);
yield return (x, y+1);
yield return (x, y-1);
}

2. Seeding with Random Noise

Randomly seed tiles with a ratio of walls to floors.

Random rnd = new Random(seed);
for (int x = 0; x < width; x++)
for (int y = 0; y < height; y++)
map[x, y] = (rnd.NextDouble() < 0.45) ? TileType.Wall : TileType.Floor;

This gives a noisy distribution, ready for smoothing.

3. Cellular Automata Smoothing

Iterate a few times applying neighbor-based rules:

TileType[,] newMap = new TileType[width, height];

for (int x = 0; x < width; x++)
for (int y = 0; y < height; y++) {
int wallCount = CountWallNeighbors8(x, y);

if (map[x, y] == TileType.Wall) {
newMap[x, y] = (wallCount >= 4) ? TileType.Wall : TileType.Floor;
} else {
newMap[x, y] = (wallCount >= 5) ? TileType.Wall : TileType.Floor;
}
}
map = newMap;

After 4–6 passes, blobs begin to look like caves.

4. Ensuring Connectivity

To prevent isolated pockets, run a flood fill from the player’s spawn point and remove unreachable areas.

void FloodFill(int startX, int startY) {
var visited = new bool[width, height];
var q = new Queue<(int,int)>();
q.Enqueue((startX, startY));
visited[startX, startY] = true;

while (q.Count > 0) {
var (cx, cy) = q.Dequeue();
foreach (var (nx, ny) in Neighbors4(cx, cy)) {
if (InBounds(nx, ny) && !visited[nx, ny] && map[nx, ny] == TileType.Floor) {
visited[nx, ny] = true;
q.Enqueue((nx, ny));
}
}
}

// Remove unreachable floors
for (int x = 0; x < width; x++)
for (int y = 0; y < height; y++)
if (map[x, y] == TileType.Floor && !visited[x, y])
map[x, y] = TileType.Wall;
}

5. Rendering in Engine

Unity: Use a Tilemap component or instantiate prefabs.
Godot: Use a TileMap node with cell placement.
Unreal: Render meshes on a grid or use Paper2D for 2D tilemaps.

Walls get colliders; floors are walkable. Add pathfinding using A* for a complete exploration system.

6. Extensions

Hybridize with room-based generation for structured layouts.
Add biomes or multiple tile types.
Store random seeds for reproducibility.
Stream large maps chunk-by-chunk.

Conclusion

We’ve built a simple but flexible 2D cave generator using cellular automata. You can extend this system for roguelikes, survival games, or sandbox exploration titles.
