In this post, you will learn how to stop your current raycasts from stealing performance and upgrade them to the new era of Unity raycast commands that finally scale.

Table of Content

Raycasting “The Traditional Way” in Unity

I’ll start by saying what high-performance developers feared and experienced all along: traditional raycasting doesn’t scale in Unity.

Calling a bunch of Physics.Raycast might be fine if your project is simple or you target 10 FPS, but in any other case you’ll want to do something else...

Something juicier...

Something that scales!

Let’s assume you want to color your crosshair depending on the “friendliness” of your target unit.

You could do something simple like this:

public class DummyCrosshair : MonoBehaviour
{
  // ...
  void Update()
  {
      bool didHitYa = Physics.Raycast(_cameraTransform.position, _cameraTransform.forward, out RaycastHit raycastHit);
      Color targetColor = Color.white;
      if (didHitYa)
      {
          if (raycastHit.collider.CompareTag("Player"))
          {
              targetColor = Color.green;
          }
          else if (raycastHit.collider.CompareTag("Enemy"))
          {
              targetColor = Color.red;
          }
      }
      _crosshairMaterial.SetColor("_Color", targetColor);
  }
}

And this is how it looks:

Crosshair Behavior

Easy, right?

After all, that was just a raycast.

Now, try to do traditional raycasting hundred times per frame without slowing your game to levels your users consider to be at the sucky level.

Even doing just a few of these raycasts is a no-go in complex projects where every drop of performance is the difference between being promoted to senior or staying as an intermediate programmer.

The main problem with traditional raycasting in Unity is that you are blocking the main thread. And blocking the main thread means angry players.

But worry no more. You are about to loot a new epic weapon that will kill these performance bottlenecks for good.

Let’s go!

The New Era: Unity Raycasting With Commands

So, how do you shoot raycasts without bothering your players through slower framerates?

Simple: by NOT blocking your main thread.

The way we avoid blocking your main thread is by using raycast commands. These commands are asynchronous, meaning that the computing happens in the background where it does not bother your user.

Only one catch...

You must change your mindset to use raycast commands in Unity. Asynchronous computing means that you don’t get the result now but in the future. So we must wait for results to be computed before coloring the crosshair.

Here are the main changes we must do:

Create the command data structures: the list of commands to send, the list of results to get back and the job handle to keep track of its computation state.
Complete and process the job results from last frame
Schedule a new raycast job for next frame.

It’s not that difficult, even if it sounds complex. This is how it looks in code:

public class DummyCrosshair : MonoBehaviour
{
  // ...
  private NativeArray<RaycastCommand> _raycastCommands;
  private NativeArray<RaycastHit> _raycastHits;
  private JobHandle _jobHandle;

  void Awake()
  {
    _raycastCommands = new NativeArray<RaycastCommand>(1, Allocator.Persistent);
    _raycastHits = new NativeArray<RaycastHit>(1, Allocator.Persistent);
  }

  private void OnDestroy()
  {
    _jobHandle.Complete();
    _raycastCommands.Dispose();
    _raycastHits.Dispose();
  }

  void Update()
  {
    // 1. Process raycast from last frame
    _jobHandle.Complete();
    RaycastHit raycastHit = _raycastHits[0];
    bool didHitYa = raycastHit.collider != null;
    Color targetColor = Color.white;
    if (didHitYa)
    {
      if (raycastHit.collider.CompareTag("Player"))
      {
        targetColor = Color.green;
      }
      else if (raycastHit.collider.CompareTag("Enemy"))
      {
        targetColor = Color.red;
      }
    }
    _crosshairMaterial.SetColor("_Color", targetColor);

    // 2. Schedule new raycast
    _raycastCommands[0] = new RaycastCommand(_cameraTransform.position, _cameraTransform.forward);
    _jobHandle = RaycastCommand.ScheduleBatch(_raycastCommands, _raycastHits, 1);
  }
}

Now this solutions SCALES. As you can see, the raycast is now executed asynchronously in the background.

Juicy, isn’t it?

It’s not “Performance by Default” (TM) yet, but Unity is making it easier for us to develop efficient code (and maybe get promoted to senior?).

Is That All?

Not really, there’s still more to discover.

For example, using Unity raycast commands introduce latency because, well, they’re asynchronous. In our example, we’re talking about 1 frame. But hey, if you’re targeting 120 FPS, no user will notice one frame.

Another thing to keep in mind is that aycasting is just one feature among many in the entire Unity ecosystem. We’ve got volumetric sweeps, checks, overlaps and much more that I cover in the lesson #022 of the Unity Performance Taskforce.

Using commands correctly becomes critical when you upgrade to volumetric sweeps because they’re exponentially more expensive. These sweeps are commonly used in game development, for example if your project uses player collisions, AI, planning, navigation and more.

Using all workers for maximum performance

If you want to know more about raycasts, make sure to watch the full lesson in the Unity Performance Taskforce. You can join the trial and well, I’ll be happy if you stay because you’ll like it :)
